Boat Media Mp3 Player

Feature:

1. This marine stereo has portable media functions, AM/FM radio, USB and auxiliary input for connecting portable media devices, and can be easily slid into the instrument opening or cup holder.

2. 4 x 45 watts of power operation, strong power, sturdy chassis and IP66 waterproof rating, can be installed in the bathroom, durable.

3. It has an AM/FM radio and RCA Aux audio input on the back. When you connect an MP3 player or flash drive to the back USB port, it can also play your digital MP3 files.

4. This unit also supports Bluetooth, which can transfer music wirelessly from your phone or similar Bluetooth devices. A line output is also provided to connect to an external amplifier.

5. Waterproof materials plus special UV coating on plastic surfaces, coated circuit boards and connections ensure that these marine and outdoor products are corrosion‑resistant.

Specification:

Item Type: Marine Bluetooth Speaker

Material: ABS+Metal

Shell Material: Metal

Purpose: Marine Speaker

Remote Control Battery: CR2025

Battery Capacity: 150mah, Battery x 1 (Built-in)

Waterproof: IP66

Power (Maximum): 80W

Application: Car, Outdoor, Yacht, Marine ATV UTV

Speaker Unit: 4

Connection Method: Bluetooth Connection

Interface Type: USB

Frequency Response Range: 60Hz-15KHz

Output Power: 4 x 45W (Up to 50W)

Signal to Noise Ratio: ≥75dB

Power Supply Mode: External 12V Power Supply

Channel: 5.1

Extended Storage: Not Supported

Bluetooth Protocol: 2.0

Number of Speakers: 4

Effective Distance: Approx. 8m/8.75yd

Operation Mode: Button

Play Format: MP3

Whether to Support APP: No

Support Format: U Disk

Speaker Adjustment Method: Button

Radio Function: Yes

1、PWR/MOD

Short press start, long press shut down.Short presson boot status is a function of [mode button]. lf there is[USB/SD card] in the computer, each short press willswitch to another function.The state is switched backand forth between[radio-USB-SD-AUX-BT], and thepower-on state automatically enters the shutdownafter pressing 3 seconds.Machine status, shutdownstatus will be automatically booted by a short press.

2/3、VOL+/VOL-

Rotate the button"VOL" clockwise to increase volume“O-40”，Rotate the button"VOL" anticlockwise to lower volume.

4.SEL

when power is on, press SEL button to select functions:BAS/TRE/BAL/FAD/LOUD/RTC.OFF.

BASS,TREB show will mode,SEL enter to VOL PressBAL,FAD,On BASS mode , turn VOL button is BASS increase 0 ,+1---+7,or will be -1,-2--- -7. And when TREB,BAL,FAD mode are the same operation as BASS.

LOUD: Switch for bass enhancement.Turn clockwise toswitch LOUD ON and OFF.

RTC.OFF: Switch for clock display.Turn clockwise toswitch clock display ON and OFF.

5、MUTE/CLK

Short press to MUTE.Long press to display time.Press and hold for 3 seconds till the hour flashes, then press VOL button to set the hour. When finish setting the hour, press CLK and the minute will flash, then press VOL button to set the minute. When finish setting , it will return to current function mode automatically in 5 seconds.lf users would like to check if the setting is successful, press CLK to check.

6、BAND/AMS

Repeated short press this key, the display screen will show[FM1],[FM2],[FM3],[AM1],[AM2] in the radio state,long press this key for 3 seconds, will automatically storethe radio.

AMS: In the radio state, press this button to execute browsing memory on the digital button, long press can automatically search and store in the digital button 1-6.ln the radio interface, short press 1-6 radio station

backward selection (jumping platform), long press forstorage station.

7/8、

TUNE/TRACK BUTTONS

A.When long pressing the TUNE/TRACK button (more than 2 seconds) during play.The speed

B.Short press the button during playback to skip to nextto track or back one track.

9.>ll/CH+

At disc playback mode, press >ll button to pause dis cplayback and the CD icon on LCD DISPLAY blinking, press it again to resume normal disc playback.Press >ll buttonfor 2 seconds will start disc playback at the first track..

ln the radio interface,press longly to select Radio Station 1-6 backward (skip),press and hold for seconds to store stations.

10.LCD

Package List:

1 x Speaker

1 x Bolt

1 x Nut

1 x Mounting Bracket

1 x Gasket

1 x Remote Controller

1 x Signal Wiring Harness

1 x Light Wire

1 x Manual
